Natural Gas Processing
Refine and purify raw natural gas with ultimate reliability
Ultra-reliable KSB pumps handle the demands of natural gas processing
- Find your best fit: You need ultra-reliable process pumps made for handling natural gas, like our RPH pumps or our RPHb/d two-stage or single-stage between bearings pumps, which reduce the load on bearings and the mechanical seal, for maximum uptime by design.
Or our versatile RPH-V vertical suspended pumps – an ideal solution for the rigorous demands of natural gas and offshore applications. - Dimensioned for heavy-duty use, our CHTR barrel-type pump is engineered for high operating reliability with highly resilient bearings, an extremely durable shaft and mechanical seals that can handle high loads.
- The vertical, high-pressure centrifugal pumps from our WKB/WKTR series are made for refinery and petrochemical applications with superior quality bearings and a shaft seal housing designed to API 682.
KSB: Your reliability professionals for natural gas processing pumps
RPH
Horizontal radially split volute casing pump in back pull-out design, to API 610, ISO 13709 (heavy duty), type OH2, single-stage, with single-suction radial impeller and centreline pump feet; with inducer if required. ATEX-compliant version available.
RPHb/RPHd/RPHbd
Heavy-duty horizontal radially split between-bearings volute casing pump to API 610, ISO 13709 (heavy duty), type BB2, with radial impellers, single- or double-entry, single- or two-stage design with centreline pump feet. ATEX-compliant version available.
CHTR
Horizontal radially split multistage high-pressure pumps in between-bearings design, with double casing (barrel-type pumps) to API 610 (ISO 13709), type BB5. First stage optionally available in double-suction design for low NPSH requirements. ATEX-compliant version available.
RPH-V
Vertical single-stage sump pump to API 610 and ISO 13709 (heavy duty), type VS4, with integral thrust bearing assembly and separate discharge line. ATEX-compliant version available.
WKTR
Vertically suspended, double-casing, lineshaft, diffuser-type pump with integral thrust bearings and discharge through column pipe in accordance with API 610 / ISO 13709 (VS6). Available in single-stage or multistage configurations and with single suction first-stage impeller.
MIL 41000
Cage-guided single-ported heavy-duty control valves, high pressure drop capability; noise reduction and anti-cavitation solution available by replacing the standard cage.
DANAÏS MT II
Double-offset butterfly valve with ISO 5211 compliant square shaft end, with plastomer seat or metal seat (fire-safe), without gland packing, maintenance-free, with lever or manual gearbox, pneumatic, electric or hydraulic actuator, body made of steel or stainless steel. Wafer-type body (T1), full-lug body (T4) or flanged body (T7) with flat or raised faces. Body types T4 and T7 are suitable for dead-end service. Connections to EN, ASME or JIS. Certified to German TA Luft Technical Guidelines on Air Quality Control.
TRIODIS 300
Triple-offset butterfly valve, metal-seated (fire-safe), without gland packing, maintenance-free, with lever or manual gearbox, pneumatic, electric or hydraulic actuator. Body made of steel or stainless steel, full-lug body (T4), flanged body (T7) with flat or raised faces, body with butt weld ends (BWSE). Body types T4 and T7 are suitable for dead-end service. Connections to EN, ASME or JIS. Connections to ASME: Schedule 40S and STD to NPS for valves with butt weld ends (other connections on request). Fugitive emissions performance tested and certified to EN ISO 15848-1. Certified to German TA Luft Technical Guidelines on Air Quality Control. Fire-safe design tested and certified to EN ISO 10497 (BS 6755 - API 6FA). ATEX-compliant version in accordance with Directive 2014/34/EU. In compliance with NACE MR0175 / ISO 15156 and MR 0103.
