The KSB valves portfolio for water applications
KSB’s valves portfolio takes care of water management, whatever the nature and variability of the task required.
KSB offers a comprehensive range of valves suitable for water applications, as well as three types of actuators and a complete range of automation products. You will find the right solution for your specific process in KSB’s wide range of valves. You will also be impressed by the long service life of our actuators.
Cleaner water and how to treat waste water as effectively as possible. These are the main challenges facing us today. Our valves are designed to meet them.
The KSB valves portfolio can deal with the challenges of producing and distributing drinking water, of collecting waste water and of purifying and recycling water so it can be used again.
Butterfly valves represent the most widely used technology on the French market and also dominate our valves portfolio.
KSB butterfly valves are designed and manufactured in the Dordogne region at the KSB Group’s international centre for butterfly valves. Their AMRING® elastomer liner is the result of formulations created by our polymer laboratory. They ensure absolute tightness in circuits used to collect, treat and transport fluids of any kind.
Butterfly valves are available as complete solutions including actuator and automation. Automation is provided by a product range designed by our teams to meet the demands of the water market.
Example of a filtration station equipped with KSB valves
BOAX-B
Centred-disc butterfly valve with ISO 5211 compliant square shaft end, sealed by elastomer liner (EPDM XC / XU or nitrile K), with lever, manual gearbox, pneumatic or electric actuator; semi-lug body (T2), full-lug body (T4). Body types T2 and T4 are suitable for downstream dismantling and dead-end service. Valve disc made of nodular cast iron or stainless steel. Connections to EN.
ISORIA 10/16
Centred-disc butterfly valve with ISO 5211 compliant square shaft end, sealed by elastomer liner, with lever or manual gearbox, pneumatic, electric or hydraulic actuator. Wafer-type body (T1), semi-lug body (T2), full-lug body (T4) or U-section body with flat faces (T5). Body types T2 and T4 are suitable for downstream dismantling and dead-end service with counterflange. Connections to EN, ASME, JIS.
MAMMOUTH
Centred-disc butterfly valve, sealed by elastomer liner, with manual gearbox, electric, hydraulic or counterweight actuator, U-section body with flat faces (T5), connections to EN, ASME or JIS.
DUALIS
Combined butterfly/check valve with single-acting hydraulically controlled counterweight actuator. For mounting on valves with DN 500 to 1400.
HERA-BD
Knife gate valve to DIN/EN with wafer-type single-piece or two-piece body made of nodular cast iron, bi-directional, with gland packing, non-rising stem, corrosion-protected by epoxy coating.
SERIE 2000
Dual-plate check valve with single-piece, wafer-type body made of lamellar graphite cast iron, nodular cast iron, steel or stainless steel; metal/elastomer-seated or metal/metal-seated, maintenance-free, connections to EN, ASME or JIS.
