Main Applications
- Hot-water heating systems
- Air-conditioning systems
- Boiler feed applications
- Boiler recirculation
Technical Data
- Nominal pressure
- PN 16, PN 25
- Max. nominal size
- DN 350
- Maximum allowable fluid temperature
- 350 °C
Material number list – BOA-H
49 productsMaterial number | Price | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| BOA-H PN 16 DN 15 5.1301 DK | DN 15 | Straight-way pattern | Throttling plug | With handwheel | Without | 3.1 kg | 48872063 | Loading... | |
| BOA-H PN 16 DN 15 5.3103 DK | DN 15 | Straight-way pattern | Throttling plug | With handwheel | Without | 3.1 kg | 48014219 | Loading... | |
| BOA-H PN 16 DN 20 5.1301 DK | DN 20 | Straight-way pattern | Throttling plug | With handwheel | Without | 4 kg | 48872064 | Loading... | |
| BOA-H PN 16 DN 20 5.3103 DK | DN 20 | Straight-way pattern | Throttling plug | With handwheel | Without | 4.1 kg | 48014220 | Loading... | |
| BOA-H PN 16 DN 25 5.1301 DK | DN 25 | Straight-way pattern | Throttling plug | With handwheel | Without | 4.7 kg | 48872065 | Loading... |
Benefits
- High operating comfort at no extra charge: position indicator with travel stop and locking device outside the insulation. Valve disc position can be checked at any time.
- Optimum start-up and throttling due to standard throttling plug up to DN 100 (seat-guided V-port plug optionally available for all valve sizes to meet maximum throttling requirements).
- When the valve is fully open, the bellows is confined within the valve body, protected from pressure surges.
Technical Data
- Function
- Shut off/control flow
- Connection type
- Flange
- Design concept Drive
- With handwheel
- Casing material
- EN-GJL-250,
EN-GJS-400-18-LT - Nominal pressure
- PN 16,
PN 25 - Max. nominal size
- DN 350
- Min. nominal size
- DN 15
- Maximum allowable fluid temperature
- 350 °C
- Minimum allowable fluid temperature
- -10 °C
- Valve body type
- Angle valve with flanged ends,
Straight-way vlv w.flngd ends
