Metals Used in Renewable Energy
KSB's extensive knowledge, along with a global support network, ensures effective metals extraction and processing specific to your operation. KSB uses system modeling tools, and proprietary pump selection software, SLYSEL, to identify the duty conditions and select the best solution for your pumping needs.
Together with our partners, our goal is to provide solutions for the production of commodities used in the renewable energy market that are ecologically responsible and sustainable.
GIW® slurry pump products are employed in the following applications:
- Extractions Ponds
- Transfer stations
- Process Plant
GIW® slurry pumps:
LCC-M
A high-efficiency slurry pump with excellent wear properties over a broad operating range. The wetted pump end (casing, impeller and suction cover / liner) is made of white cast iron with a high chromium content. Design optimised for easy dismantling and reassembly for maintenance and inspection work. The maximum permissible working pressures are between 8 and 16 bar, depending on the pump size. Perfectly suited for transporting fluids containing hardly to slightly abrasive solids. Ideal for sludges, classes 1 to 2.
LSA
Robust, proven, high-efficiency pump for high heads with pump components made of abrasion-resistant white cast iron, designed for the hydraulic transport of solids of the most various particle sizes, in the most diverse of operating conditions. Robust, proven, reliable and service-friendly
MDX
Pump designed with the latest technology from GIW. Superior wear properties and extremely long service life handling aggressive slurries.
KSB pumps
MegaCPK
Horizontal radially split volute casing pump in back pull-out design, with radial impeller, single-entry, single-stage, to DIN EN ISO 5199, dimensions to DIN EN ISO 2858, complemented by nominal diameters DN25 and ≥DN200, in large range of material and seal variants; also available as a variant with "wet" shaft and conical seal chamber. ATEX-compliant version available.
CPKN
Horizontal radially split volute casing pump in back pull-out design, with radial impeller, single-entry, single-stage, to ISO 2858 / ISO 5199. Also available as a variant with "wet" shaft, conical seal chamber and/or semi-open impeller. ATEX-compliant version available.
KWP
Horizontal radially split volute casing pump in back pull-out design, single-stage, single-entry, available with various impeller types: closed multi-channel impeller, open multi-vane impeller and vortex impeller. ATEX-compliant version available.
Multitec
Multistage horizontal or vertical centrifugal pump in ring-section design, long-coupled or close-coupled, with axial or radial suction nozzle, cast radial impellers and motor-mounted variable speed system. ATEX-compliant version available.
Movitec
Multistage vertical high-pressure centrifugal pump in ring-section design with suction and discharge nozzles of identical nominal diameters arranged opposite to each other (in-line design), close-coupled. With KSB SuPremE, a magnetless synchronous reluctance motor (exception: motor sizes 0.55 kW / 0.75 kW with 1500 rpm are designed with permanent magnets) of efficiency class IE4/IE5 to IEC TS 60034-30-2:2016, for operation on a KSB PumpDrive 2 or KSB PumpDrive 2 Eco variable speed system without rotor position sensors. Motor mounting points in accordance with EN 50347, envelope dimensions in accordance with DIN V 42673 (07-2011). ATEX-compliant version available.
