Bulk Chemicals Production
KSB pumps help maximise uptime – keeping bulk process plants running smoothly and profitably.
The global chemical industry depends on competitively-priced bulk chemicals. We help keep your production processes flowing, so you can focus on safe operation and boost your bottom line.
Rise to the challenge with dependable chemical pump solutions
No matter whether your large-scale manufacturing plant specialises in polymers, petrochemical derivatives, metals, minerals or organometallic compounds, you demand absolute reliability and zero leakage – around the clock. After all, you need to keep production high while working to strict health and environmental standards. Rest assured: We’ve developed our products and services with you in mind.
High-reliability KSB pumps for the chemical industry – day after day
When you’re running a bulk process plant producing competitively-priced chemicals, facility uptime is a major factor that determines your overall profitability. Dependable fluid-handling equipment is essential to keep bulk production processes flowing. This is why our partners in chemicals production consistently turn to KSB.
Find your perfect fit: Our extensive portfolio for bulk chemical manufacturing includes corrosion-resistant, standardised chemical pumps and process pumps, seal-less pumps, and much more.
- Our MegaCPK is, quite simply, the best standardised chemical pump in its class. Optimised hydraulic components set new standards in energy efficiency, while low NPSH ensures that the pump runs quietly and smoothly.
- The Magnochem magnetic drive pump series, available in numerous variants, also meets the most stringent customer requirements.
- The CPKN is ideal for pumping aggressive organic and inorganic fluids in chemical process engineering.
- And the Estigia vertical immersion pump is available in an ATEX-compliant version.
Reliably handling everything from hot acids to solids-laden lyes, KSB pumps are more than tough enough for chemical industry.
How KSB supports bulk chemical production
We are familiar with the extreme conditions in and around your equipment. KSB’s advanced fluid-handling technologies ensure that aggressive, corrosive and explosive fluids are transported and contained safely. Our expertly engineered pumps offer trouble-free, efficient operation along with low life cycle costs. And we deliver more than rugged, reliable products – we also support you with installation and commissioning, inspection and maintenance. Should repairs ever be necessary, we come to you.
What keeps our bulk chemicals partners coming back to KSB? Easy: They trust our extensive knowledge and proven performance to enable continuous manufacturing and ensure a healthy bottom line.
MegaCPK
Horizontal radially split volute casing pump in back pull-out design, with radial impeller, single-entry, single-stage, to DIN EN ISO 5199, dimensions to DIN EN ISO 2858, complemented by nominal diameters DN25 and ≥DN200, in large range of material and seal variants; also available as a variant with "wet" shaft and conical seal chamber. ATEX-compliant version available.
Magnochem
Horizontal seal-less volute casing pump in back pull-out design, with magnetic drive, to DIN EN ISO 2858 / ISO 5199, with radial impeller, single-entry, single-stage. ATEX-compliant version available.
Estigia
Vertical immersion pump for wet installation, with various impeller types designed to meet specific fluid requirements. Supplied with discharge pipe extending above the cover plate, DN according to nominal flow rate. Sealing by lip seal, single or double cartridge mechanical seal. ATEX-compliant version available.
KE
Centred-disc butterfly valve with ISO 5211 compliant square shaft end and PFA liner. With lever, manual gearbox, pneumatic or electric actuator. With wafer-type body (T1), full-lug body (T4) or U-section body with raised faces (T6). EN, ASME, JIS connections possible.
ISORIA 10/16
Centred-disc butterfly valve with ISO 5211 compliant square shaft end, sealed by elastomer liner, with lever or manual gearbox, pneumatic, electric or hydraulic actuator. Wafer-type body (T1), semi-lug body (T2), full-lug body (T4) or U-section body with flat faces (T5). Body types T2 and T4 are suitable for downstream dismantling and dead-end service with counterflange. Connections to EN, ASME, JIS.
SISTO-20
Weir-type diaphragm valve to DIN/EN with flanged ends, threaded socket ends or socket weld ends, in straight-way pattern; shut-off and sealing to atmosphere by supported and confined diaphragm; body with coating or lining, position indicator with integrated stem protection. All moving parts are separated from the fluid by the diaphragm. Maintenance-free.
KE
Centred-disc butterfly valve with ISO 5211 compliant square shaft end and PFA liner. With lever, manual gearbox, pneumatic or electric actuator. With wafer-type body (T1), full-lug body (T4) or U-section body with raised faces (T6). EN, ASME, JIS connections possible.
ISORIA 10/16
Centred-disc butterfly valve with ISO 5211 compliant square shaft end, sealed by elastomer liner, with lever or manual gearbox, pneumatic, electric or hydraulic actuator. Wafer-type body (T1), semi-lug body (T2), full-lug body (T4) or U-section body with flat faces (T5). Body types T2 and T4 are suitable for downstream dismantling and dead-end service with counterflange. Connections to EN, ASME, JIS.
SISTO-20
Weir-type diaphragm valve to DIN/EN with flanged ends, threaded socket ends or socket weld ends, in straight-way pattern; shut-off and sealing to atmosphere by supported and confined diaphragm; body with coating or lining, position indicator with integrated stem protection. All moving parts are separated from the fluid by the diaphragm. Maintenance-free.
