Full throttle into the future: intelligent solutions for climate-neutral fuels
In order to limit global warming to 1.5 °C, the states that ratified the Paris Climate Agreement are committed to making climate-friendly changes to their economies, including the mobility sector. Previously, fossil fuels that produced large volumes of CO2 emissions were burned. Today, however, more sustainable solutions are in demand, with carbon-neutral, non-fossil fuels becoming increasingly important.
It's time to step up a gear – for the sake of our climate!
Technical innovation has been a strong tradition at KSB for 150 years. Developing innovative solutions is our daily work. For many years now, KSB has also been active in the area of non-fossil fuels and synthetic fuels. It knows the processes involved and can offer a whole host of state-of-the-art products.
Non-fossil fuels and synthetic fuels are gaining importance, especially in those industries in which electrification is only feasible in the long term (for example, shipping and aviation).
Non-fossil fuel is mostly liquid fuel produced from biomass for use in combustion engines. Renewable raw materials such as rapeseed, sugar beet, wood, straw and residues from the food processing industry can be used as basis. The most important types of non-fossil fuels are biodiesel, bioethanol, biomethane and vegetable oil (rapeseed oil).
Synthetic fuels or synfuels are produced from a mixture of isolated carbon dioxide and climate-neutral hydrogen. These fuels are currently in the development phase. However, they will play a major role in the future, especially in industries that are not easily electrified
Whether you are a consultant, licensor, engineering contractor or operator, you need a partner who is familiar with this topic and understands your needs. KSB has both the necessary expertise and the right products for you:
Pumps used in fermentation and transesterification processes operate under the toughest conditions. Thanks to their large range of seal and material variants, our MegaCPK and Magnochem standardised chemical pump series are particularly suitable for aggressive fluids. In process steps involving solids-laden fluids, our KWP series impresses with its wear-resistant design and impeller variance.
In secondary processes, our ETA series pumps ensure reliable and efficient water transport. KSB’s Movitec, Multitec and HG series provide the necessary water pressure through their multistage design.
In addition to our extensive pump range, we also supply valves that are suitable for a variety of process fluids and supply fluids. These include manual, actuated and controlled valves as well as those equipped with positioners:
The ISORIA butterfly valve is an all-rounder. With over three million standard variants, this valve is extremely versatile.
The double-offset DANAIS butterfly valve can also easily handle high temperatures.
The KE butterfly valves and the SISTO diaphragm valves are the right solutions for aggressive fluids or special requirements relating to emissions control.
As a full-range supplier, we are able to equip entire systems with the necessary pumps, valves and automation solutions. We provide products to the API and ISO standards, including mag-drive pumps, suitable mechanical seals, and lots more. Moreover, an ATEX-compliant version of our intelligent monitoring solution, KSB Guard, is available to facilitate smart monitoring of systems.
Thanks to our technical excellence and passion for innovative solutions in the area of eco-friendly technologies, we are making an important contribution towards greater sustainability and therefore a better future. Welcome to the world of green solutions!
MegaCPK
Horizontal radially split volute casing pump in back pull-out design, with radial impeller, single-entry, single-stage, to DIN EN ISO 5199, dimensions to DIN EN ISO 2858, complemented by nominal diameters DN25 and ≥DN200, in large range of material and seal variants; also available as a variant with "wet" shaft and conical seal chamber. ATEX-compliant version available.
Magnochem
Horizontal seal-less volute casing pump in back pull-out design, with magnetic drive, to DIN EN ISO 2858 / ISO 5199, with radial impeller, single-entry, single-stage. ATEX-compliant version available.
CPKN
Horizontal radially split volute casing pump in back pull-out design, with radial impeller, single-entry, single-stage, to ISO 2858 / ISO 5199. Also available as a variant with "wet" shaft, conical seal chamber and/or semi-open impeller. ATEX-compliant version available.
RPHb/RPHd/RPHbd
Heavy-duty horizontal radially split between-bearings volute casing pump to API 610, ISO 13709 (heavy duty), type BB2, with radial impellers, single- or double-entry, single- or two-stage design with centreline pump feet. ATEX-compliant version available.
ISORIA 10/16
Centred-disc butterfly valve with ISO 5211 compliant square shaft end, sealed by elastomer liner, with lever or manual gearbox, pneumatic, electric or hydraulic actuator. Wafer-type body (T1), semi-lug body (T2), full-lug body (T4) or U-section body with flat faces (T5). Body types T2 and T4 are suitable for downstream dismantling and dead-end service with counterflange. Connections to EN, ASME, JIS.
DANAÏS MT II
Double-offset butterfly valve with ISO 5211 compliant square shaft end, with plastomer seat or metal seat (fire-safe), without gland packing, maintenance-free, with lever or manual gearbox, pneumatic, electric or hydraulic actuator, body made of steel or stainless steel. Wafer-type body (T1), full-lug body (T4) or flanged body (T7) with flat or raised faces. Body types T4 and T7 are suitable for dead-end service. Connections to EN, ASME or JIS. Certified to German TA Luft Technical Guidelines on Air Quality Control.
KE
Centred-disc butterfly valve with ISO 5211 compliant square shaft end and PFA liner. With lever, manual gearbox, pneumatic or electric actuator. With wafer-type body (T1), full-lug body (T4) or U-section body with raised faces (T6). EN, ASME, JIS connections possible.
SISTO-20
Weir-type diaphragm valve to DIN/EN with flanged ends, threaded socket ends or socket weld ends, in straight-way pattern; shut-off and sealing to atmosphere by supported and confined diaphragm; body with coating or lining, position indicator with integrated stem protection. All moving parts are separated from the fluid by the diaphragm. Maintenance-free.
SISTO-20
Weir-type diaphragm valve to DIN/EN with flanged ends, threaded socket ends or socket weld ends, in straight-way pattern; shut-off and sealing to atmosphere by supported and confined diaphragm; body with coating or lining, position indicator with integrated stem protection. All moving parts are separated from the fluid by the diaphragm. Maintenance-free.
KSB Guard
The smart and comprehensive monitoring service for pumps and other rotating machinery, available 24/7 and also for non-KSB pumps. Benefit from predictive maintenance with KSB: comprehensive transparency, increased availability, enhanced operating reliability and efficient operation (of fixed-speed pumps). Important operating data such as vibrations, temperature, operating hours and load condition (of fixed-speed pumps) can be accessed via KSB Guard, anytime and from anywhere. In addition, deviations from normal operation trigger immediate notifications via the KSB Guard web portal and/or app. The experts at the KSB Monitoring Centre also provide support in analysing causes.
