Evamatic-Box N

Evamatic-Box N

Floodable lifting unit for domestic waste water, equipped with either one or two pumps of type Ama-Porter F (vortex impeller) or Ama-Porter S (cutter)
See all documents and downloads

Main Applications

  • Waste water disposal
  • Automatic drainage of buildings and premises below the flood level
  • Drainage systems
  • Rainwater harvesting

Technical Data

Max. flow rate
40 m3/h
Max. head
21 m
Maximum allowable fluid temperature
40 °C

Material number list – Evamatic-Box N

57 products
Material number
Price
Evamatic Box N 132 ULG-S-M70 kg39023840
Loading...
Evamatic Box N 1500 E-S-M70 kg39023561
Loading...
Evamatic-Box N 1500 E-P-K54 kg39023380
Loading...
Evamatic-Box N 1500 E-S-K70 kg39023388
Loading...
Evamatic-Box N 1501 E-P-K54 kg39023381
Loading...

Benefits

  • Control unit enables automatic pump operation
  • Easy installation, above-floor or underfloor
  • Pump can easily be lifted out of and lowered into the tank through the large access opening (tank cover).

Technical Data

Connection type
External-thread connection
Drive concept
With electric actuator
Max. flow rate
40 m3/h
Min. flow rate
0.1 m3/h
Max. head
21 m
Min. head
1 m
Mains frequency
50 Hz
Mains voltage
400 V
Casing material
EN-GJL-200
Suction behaviour
Non-self-priming
Maximum allowable fluid temperature
40 °C
Minimum allowable fluid temperature
0 °C

Characteristic curves

Sectional Drawings
