Main Applications
- Water supply systems
- Spray irrigation systems
- Mining
- General irrigation systems
Technical Data
- Max. flow rate
- 310 m3/h
- Max. head
- 480 m
- Max. allowed working pressure
- 60 bar
- Maximum allowable fluid temperature
- 60 °C
Benefits
- High efficiencies through optimised hydraulic design
- High operating reliability and a long service life by integrated sand separator, robust wear rings and enclosed pump bearings
- Reliable operation by anti-jam lift check valve
The Art of UPA - what makes a borehole pump so special?
In a short video, our expert presents the advantages of the UPA S 250 in detail. Learn more about its performance, the various aspects for a long service life and: how you can possibly save 15,000 € per year thanks to a better efficiency.
The Art of UPA - what makes a borehole pump so special?
In a short video, our expert presents the advantages of the UPA S 250 in detail. Learn more about its performance, the various aspects for a long service life and: how you can possibly save 15,000 € per year thanks to a better efficiency.
Technical Data
- Function
- Pump
- Connection type
- Internal-thread connection,
Flange - Drive concept
- With electric actuator
- Max. flow rate
- 310 m3/h
- Min. flow rate
- 70 m3/h
- Max. head
- 480 m
- Min. head
- 5 m
- Mains frequency
- 60 Hz
- Mains voltage
- 230 V,
380 V,
400 V,
415 V,
460 V,
500 V,
690 V,
1000 V - Casing material
- X1NICRMOCU25-20-5,
CUSN10-C,
(EN-GJL-200) BASIC MATERIAL GROUP - Nominal pressure
- PN 63
- Max. allowed working pressure
- 60 bar
- Suction behaviour
- Non-self-priming
- Maximum allowable fluid temperature
- 60 °C
- Minimum allowable fluid temperature
- 0 °C
