Dry-installed pump Megaline

Volute casing pump for horizontal or vertical installation, in back pull-out design, single-stage, radially split volute casing, replaceable casing wear rings. Volute casing in in-line design with closed radial impeller, with multiply curved vanes, single mechanical seal to EN 12756.

See all documents and downloads

Main Applications

Service water supply systems
Heating systems
Industrial recirculation systems
Air-conditioning systems

Technical Data

Max. flow rate: 600 m3/h
Max. head: 135 m
Max. allowed working pressure: 16 bar
Maximum allowable fluid temperature: 90 °C

	Material number	Status	Estimated delivery	Price
MLIN032-032-160 GGF AA 03002B	05044300	Loading...	Loading...	Loading...
MLIN032-032-160 GGF AA 03702B	05044301	Loading...	Loading...	Loading...
MLIN032-032-160 GGF AA 04502B	05044302	Loading...	Loading...	Loading...
MLIN032-032-160 GGF AA 05502B	05044303	Loading...	Loading...	Loading...
MLIN032-032-200 GGF AA 00754B	05044399	Loading...	Loading...	Loading...

Benefits

Improved efficiency and NPSHreq by experimentally verified hydraulic design of impellers (vanes)
Operating costs reduced by trimming the nominal impeller diameter to match the specified duty point
Little wear, low vibration levels and excellent smooth running characteristics thanks to good suction performance and virtually cavitation-free operation across a wide operating range

Technical Data

Function: Pump
Drive concept: With electric actuator
Max. flow rate: 600 m3/h
Max. head: 135 m
Max. allowed working pressure: 16 bar
Suction behaviour: Non-self-priming
Maximum allowable fluid temperature: 90 °C
