The fully floodable submersible motor pump is used wherever grey water has to be pumped off reliably, fast and efficiently, e.g. for draining underground car parks, buildings or retention tanks. We have made some major additions to the AmaPorter type series, now offering you a suitable version for practically every scenario.
AmaPorter: Easy. For everyone.
The fully floodable submersible motor pump is used wherever grey water has to be pumped off reliably, fast and efficiently, e.g. for draining underground car parks, buildings or retention tanks. We have made some major additions to the AmaPorter type series, now offering you a suitable version for practically every scenario.
More variants – more options for you.
The idea behind AmaPorter: Making it as easy as possible for all parties involved, from selection and procurement to installation and operation. Our tried and tested AmaPorter family, established for many years, is now available in even more sizes and variants. Having added numerous model variants, KSB can now offer you more options and a perfect match for almost any application.
Impeller/ connection | F / DN50 | F / DN65 | F / DN80 | S / DN50 |
Flow rate Q | ≤ 46 m³/h | ≤ 80 m³/h | ≤ 130 m³/h | ≤ 17 m³/h |
Head H | ≤ 37 m | ≤ 22 m | ≤ 13 m | ≤ 21 m |
Power P | 0,55 - 4,2 kW | 0,75 - 1,8 kW | 1,9 - 3,7 kW | 1,1 - 1,5 kW |
Voltage V | 1 ~ 230 V | 1 ~ 230 V | 3 ~ 400 V | 1 ~ 230 V |
ATEX | – | – | – | – |
Free passage | 40 - 45 mm | 56 - 65 mm | 76 mm | 7 mm |
How can we be of assistance? Make use of our free initial consultation.
Have you got any questions about AmaPorter, would you like support in selecting your pump or do you need any tips on maintenance and installation? Or would you like to receive an individual quotation? Simply fill in the form – our experts will be pleased to call you.Products
AmaPorter
Vertical single-stage submersible motor pump (grey cast iron) for waste water in close-coupled design for wet installation, stationary or transportable version.
LevelControl Basic 2
Level control unit for controlling and protecting either one or two pumps. DOL starting up to 4 kW, star-delta starting up to 22 kW. Higher ratings on request.
